- 125kHz EM or 13.56MHz Mifare card reader
- Wiegand interface
- Baca jarak hingga 10 cm untuk kartu proximity dan 5cm untuk kartu Mifare
- • Kontrol LED eksternal
- • Kontrol Buzzer Eksternal
- • Indoor / Outdoor operasi
- • Epoxy solid pot
- • Waterproof IP64 atau IP65
- • Perlindungan Polaritas Balik
-
Technical Specifications
Read Range
• KRxxx-E: Up to 10CM • KRxxx-M: Up to 5CM
Reading Time
• ≤200ms
Input Port
• External LED Control • External Buzzer Control
Output Port
• KRxxx-E: 26bit Wiegand (Default) • KRxxx-M: 34bit Wiegand (Default)
Power/Current
• DC 6-14V / Max.70mA
LED
• Red and Green LEDs
Operating Temperature
• -10°C to +65°C
Material
• ABS+PC with texture
Operating Humidity
• 10% to 90% relative humidity • non-condensing
Beeper
• Yes
Index of Protection
• KR500-E/M: IP65 • KR501-E/M: IP65 • KR502-E/M: IP64 • KR503-E/M: IP65
