- IP65 rated waterproof and dustproof structure
- Optional 8,000 Fingerprint
- Network interface by TCP/IP or RS485
- Full Access Control Features
-
Technical Specifications
Fingerprint Sensor
Infrared detection fingerprint sensor
Algorithm Version
ZK Finger VX10.0
Communication
TCP/IP, RS485, USB Host
Fingerprint Capacity
3,000 Fingerprints(8,000 Optional)
Card Capacity
10,000 Cards
Log Capacity
50,000 Transactions
RF Card
EM(standard)/Mifare(optional)
Authentication
Finger/PIN/Card
Wiegand Signal
Wiegand input&output
Ingress Protection Rate
IP65
Display
128 x 64 OLED
Keypad
3 x 5 keypads & doorbell
Sound and Interface
Buzzer and multi-color LED
Operating Voltage
12VDC 3A
Operating Temperature
-10 °C~50 °C (14°F ~ 122°F)
Dimension
62.5mm×185mm×41.5mm (W×H×D)
